PRODUCT INFORMATION
GAMMAXX L240 V2
Reliable & Viable
GAMMAXX L series AIO coolers are known for their high performance, neat appearance, and cost efficiency.
The GAMMAXX L240 V2 upgraded its reliability with "Anti-leak Tech Inside" system, so users can enjoy extreme processor cooling performance without any leakage concerns.
About Anti-leak Tech Inside
After 3 years of R&D, DeepCool launched the new standard of liquid cooling system - The Anti-leak Tech.
This technology helps your system balance its pressure, significantly improving operation safety of AIO liquid cooling systems. With this technology, DeepCool is setting a new standard for liquid cooling systems.
Optimized Micro Water-channel
E-shaped micro water-channel design can effectively enhance the heat circulation efficiency and enlarge the thermal contact area.
Motherboard Control RGB SYNC
The brand new water block and fans built-in 12V RGB lighting system gives you the possibility to customize your lighting through mainstream motherboards with synchronized lighting control.
Compatible with...
- Asus Aura Sync
- Razer Chroma RGB
- Gigabyte RGB Fusion
- MSI Mystic Light Sync
- ASROCK Polychrome Sync
Support Mainstream Intel & AMD Socket
Ready for easy mounting and unrestricted direction installation on mainstream sockets of Intel/AMD.
PWM Control & RGB Fan
The 2 included 120mm RGB fans come with 6 ultra-bright RGB LED lights and PWM control with super silent performance.
Model
GAMMAXX L240 V2
Socket Compatibility
Intel: LGA20XX / LGA1366 / LGA1200 / 1151 / 1150 / 1155
AMD: AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1
Model Number
DP-H12RF-GL360V2C
Pump Specifications
Dimensions: 91 x 79 x 47 mm
Speed: 2400RPM ± 10%
Noise: 17.8 dB(A)
Connector: 3-pin
Rated Voltage: 12 VDC
Rated Current: 0.2 A
Power Consumption: 2.4 W
Radiator Specifications
Dimensions: 282 x 120 x 27 mm
Material: Aluminum
Tube length: 380 mm
Fan Specifications
Dimensions: 120 x 120 x 25 mm
Speed: 500~1800 RPM ± 10%
Airflow: 69.34 CFM
Air Pressure: 2.42 mmAq
Noise: =30 dB(A)
Connector: 4-pin
Bearing Type: Hydro Bearing
Rated Voltage: 12 VDC
Rated Current: 0.17 A
Power Consumption: 2.04 W
LED Type: RGB LED
LED Connector: 4-pin(12V-G-R-B)
LED Rated Voltage: 12 VDC
LED Power Consumption: 0.84 W(PUMP)/ 2.88 W(FAN x 2)
Weight
Net: 1.320 kgs
