PRODUCT INFORMATION
Dynamic performance
While the compact Lenovo V50s leaves a small footprint, it’s got the power you need to keep your business productive. 10th Gen Intel® Core™ processors let users multitask and handle extensive multimedia projects efficiently. Optional discrete graphics render life-like visuals and provide crisp detail to your business presentations.
Fast memory & storage
The Lenovo V50s lets you enjoy seamless multitasking thanks to up to 32GB DDR4 memory. Storage options include up to 1TB M.2 PCIe SSD NVMe and up to 3.5” 2TB SATA hard drives. And the V50s’ specially engineered BIOS improves cold boot times by at least 5 seconds—even on SSD
Control your costs
Engineered for reduced power consumption and near-silent operation, the Lenovo V50s lets you cut down on both energy costs and noise—it’s certified for low noise and energy efficiency. Front air vents improve air circulation, while an upgraded cooling system lets you boost performance or run quietly depending on the circumstances.
Control your data
The Lenovo V50s is hardwired with Trusted Platform Module firmware to encrypt data and passwords. It has Smart USB protection to prevent rogue USB use, and an optional tamper-proof clip for the cables connected to the ports. And there’s a Kensington lock slot and padlock loop to physically secure the PC.
SPECIFICATIONS
PERFORMANCE
Processor:
Intel Core i5-10500 (6C / 12T, 3.1 / 4.5GHz, 12MB)
Graphics:
Integrated Intel UHD Graphics 630
Chipset:
Intel H470 Chipset
Memory:
1x 8GB UDIMM DDR4-2666
Memory Slots:
Four DDR4 DIMM slots, dual-channel capable
Max Memory:
Up to 128GB DDR4-2933
Storage:
1x 256GB SSD M.2 2280 PCIe x4 NVMe Opal
Optane Memory:
None
Storage Support:
Up to three drives, 1x 2.5 Inch/3.5 Inch HDD + 1x 2.5 Inch HDD + 1x M.2 SSD
• 2.5 Inch HDD up to 1TB each
• 3.5 Inch HDD up to 2TB
• M.2 SSD up to 2TB
• Optional Intel Optane Memory, M.2
Card Reader:
3-in-1 Card Reader
Optical:
DVD±RW
Audio Chip:
High Definition (HD) Audio, Realtek ALC623-CG codec
Speakers:
1Wx1
Power Supply:
180W 85%
DESIGN
Keyboard:
USB Traditional Keyboard, Black, English (UK)
Mouse:
USB Calliope Mouse, Black
Front Access HDD:
None
Optional Bay:
None
Expansion Slots:
One PCIe 3.0 x1, low-profie (length < 155mm, height < 68mm)
One PCIe 3.0 x16, low-profie (length < 155mm, height < 68mm)
Two dummy slots, only brackets for optional port extension
Two M.2 slots (one for WLAN, one for SSD)
Case Color:
Black
Stand:
None
Carry Handle:
None
Dust Filter:
None
Form Factor:
SFF (8.2L)
Dimensions (WxDxH):
93 x 298 x 340 mm (3.6 x 11.7 x 13.4 inches)
Weight:
5.3 kg (11.7 lbs)
CONNECTIVITY
Ethernet:
Integrated 100/1000M
WLAN + Bluetooth:
None
Front Ports:
2x USB 3.2 Gen 1
2x USB 3.2 Gen 2
1x USB-C 3.2 Gen 1
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)
Optional Front Ports (configured)
1x card reader
Rear Ports:
4x USB 2.0
1x HDMI
2x DisplayPort
1x serial (9-pin)
1x Ethernet (RJ-45)
1x line-out (3.5mm)
Optional Rear Ports (configured):
None
Monitor Cable:
None
SECURITY & PRIVACY
Security Chip:
Discrete TPM 2.0, TCG certified
Fingerprint Reader:
No fingerprint reader
Physical Locks:
Kensington Security Slot
Padlock Loop:
Kensington Cable Lock
None
Smart Cable Clip:
None
Chassis E-Lock:
None
MANAGEABILITY
System Management:
None
SERVICE
Base Warranty:
3-year, Onsite
Included Upgrade:
None
CERTIFICATIONS
Green Certifications:
ErP Lot 3
TCO Certified 8.0
RoHS compliant
Mil-Spec Test:
MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Fungus, Solar Radiation)
SOFTWARE
Operating System:
Windows 10 Pro 64, English
Bundled Software:
None
While the compact Lenovo V50s leaves a small footprint, it’s got the power you need to keep your business productive. 10th Gen Intel® Core™ processors let users multitask and handle extensive multimedia projects efficiently. Optional discrete graphics render life-like visuals and provide crisp detail to your business presentations.
Fast memory & storage
The Lenovo V50s lets you enjoy seamless multitasking thanks to up to 32GB DDR4 memory. Storage options include up to 1TB M.2 PCIe SSD NVMe and up to 3.5” 2TB SATA hard drives. And the V50s’ specially engineered BIOS improves cold boot times by at least 5 seconds—even on SSD
Control your costs
Engineered for reduced power consumption and near-silent operation, the Lenovo V50s lets you cut down on both energy costs and noise—it’s certified for low noise and energy efficiency. Front air vents improve air circulation, while an upgraded cooling system lets you boost performance or run quietly depending on the circumstances.
Control your data
The Lenovo V50s is hardwired with Trusted Platform Module firmware to encrypt data and passwords. It has Smart USB protection to prevent rogue USB use, and an optional tamper-proof clip for the cables connected to the ports. And there’s a Kensington lock slot and padlock loop to physically secure the PC.
SPECIFICATIONS
PERFORMANCE
Processor:
Intel Core i5-10500 (6C / 12T, 3.1 / 4.5GHz, 12MB)
Graphics:
Integrated Intel UHD Graphics 630
Chipset:
Intel H470 Chipset
Memory:
1x 8GB UDIMM DDR4-2666
Memory Slots:
Four DDR4 DIMM slots, dual-channel capable
Max Memory:
Up to 128GB DDR4-2933
Storage:
1x 256GB SSD M.2 2280 PCIe x4 NVMe Opal
Optane Memory:
None
Storage Support:
Up to three drives, 1x 2.5 Inch/3.5 Inch HDD + 1x 2.5 Inch HDD + 1x M.2 SSD
• 2.5 Inch HDD up to 1TB each
• 3.5 Inch HDD up to 2TB
• M.2 SSD up to 2TB
• Optional Intel Optane Memory, M.2
Card Reader:
3-in-1 Card Reader
Optical:
DVD±RW
Audio Chip:
High Definition (HD) Audio, Realtek ALC623-CG codec
Speakers:
1Wx1
Power Supply:
180W 85%
DESIGN
Keyboard:
USB Traditional Keyboard, Black, English (UK)
Mouse:
USB Calliope Mouse, Black
Front Access HDD:
None
Optional Bay:
None
Expansion Slots:
One PCIe 3.0 x1, low-profie (length < 155mm, height < 68mm)
One PCIe 3.0 x16, low-profie (length < 155mm, height < 68mm)
Two dummy slots, only brackets for optional port extension
Two M.2 slots (one for WLAN, one for SSD)
Case Color:
Black
Stand:
None
Carry Handle:
None
Dust Filter:
None
Form Factor:
SFF (8.2L)
Dimensions (WxDxH):
93 x 298 x 340 mm (3.6 x 11.7 x 13.4 inches)
Weight:
5.3 kg (11.7 lbs)
CONNECTIVITY
Ethernet:
Integrated 100/1000M
WLAN + Bluetooth:
None
Front Ports:
2x USB 3.2 Gen 1
2x USB 3.2 Gen 2
1x USB-C 3.2 Gen 1
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)
Optional Front Ports (configured)
1x card reader
Rear Ports:
4x USB 2.0
1x HDMI
2x DisplayPort
1x serial (9-pin)
1x Ethernet (RJ-45)
1x line-out (3.5mm)
Optional Rear Ports (configured):
None
Monitor Cable:
None
SECURITY & PRIVACY
Security Chip:
Discrete TPM 2.0, TCG certified
Fingerprint Reader:
No fingerprint reader
Physical Locks:
Kensington Security Slot
Padlock Loop:
Kensington Cable Lock
None
Smart Cable Clip:
None
Chassis E-Lock:
None
MANAGEABILITY
System Management:
None
SERVICE
Base Warranty:
3-year, Onsite
Included Upgrade:
None
CERTIFICATIONS
Green Certifications:
ErP Lot 3
TCO Certified 8.0
RoHS compliant
Mil-Spec Test:
MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Fungus, Solar Radiation)
SOFTWARE
Operating System:
Windows 10 Pro 64, English
Bundled Software:
None
